Digital Oscilloscopes
Digital Oscilloscopes
Digital Oscilloscopes
Whether you are a hobbyist, an educator, a developer, or are debugging, performing compliance tests, you need proven measurement technology to be successful. From basic measurements to deep-analysis, UNI-T digital oscilloscopes are built on the same, proven UNI-T technology with product range from MSO oscilloscopes to portable form. You are sure to find the right oscilloscope with an unprecedented price.
MSO7000X
MSO7000X
BANDWIDTH:1GHz~2GHz
ANALOG CHANNELS:4
REAL-TIME SAMPLE RATE:10GSa/s
MAX. MEMORY DEPTH:1Gpts
WAVEFORM CAPTURE RATE:2,000,000wfms/s
DIGITAL CHANNELS:16(optional)
STARTING PRICE:
MSO3000HD
MSO3000HD
BANDWIDTH:200 MHz~500 MHz
ANALOG CHANNELS:4
REAL-TIME SAMPLE RATE:2.5GSa/s
MAX. MEMORY DEPTH:500Mpts
WAVEFORM CAPTURE RATE:1,500,000wfms/s
DIGITAL CHANNELS:16
STARTING PRICE:
MSO3000X
MSO3000X
BANDWIDTH:350MHz~500MHz
ANALOG CHANNELS:4
REAL-TIME SAMPLE RATE:5GSa/s
MAX. MEMORY DEPTH:500Mpts
WAVEFORM CAPTURE RATE:2,000,000wfms/s
DIGITAL CHANNELS:16
STARTING PRICE:
MSO/UPO3000E
MSO/UPO3000E
BANDWIDTH:350MHz~500MHz
ANALOG CHANNELS:2/4
REAL-TIME SAMPLE RATE:2.5GSa/s
MAX. MEMORY DEPTH:250Mpts
WAVEFORM CAPTURE RATE:1,000,000wfms/s
DIGITAL CHANNELS:16
STARTING PRICE:
MSO2000X
MSO2000X
BANDWIDTH:100MHz~300MHz
ANALOG CHANNELS:4
REAL-TIME SAMPLE RATE:5GSa/s
MAX. MEMORY DEPTH:100Mpts
WAVEFORM CAPTURE RATE:2,000,000wfms/s
DIGITAL CHANNELS:16
STARTING PRICE:
MSO/UPO2000
MSO/UPO2000
BANDWIDTH:100MHz~200MHz
ANALOG CHANNELS:2/4
REAL-TIME SAMPLE RATE:2GSa/s
MAX. MEMORY DEPTH:56Mpts
WAVEFORM CAPTURE RATE:1,000,000wfms/s
DIGITAL CHANNELS:16
STARTING PRICE:
UPO1000
UPO1000
BANDWIDTH:50MHz~200MHz
ANALOG CHANNELS:4
REAL-TIME SAMPLE RATE:2GSa/s
MAX. MEMORY DEPTH:56Mpts
WAVEFORM CAPTURE RATE:500,000wfms/s
DIGITAL CHANNELS:/
STARTING PRICE:
UPO1000CS
UPO1000CS
BANDWIDTH:100MHz~200MHz
ANALOG CHANNELS:2
REAL-TIME SAMPLE RATE:1GSa/s
MAX. MEMORY DEPTH:56Mpts
WAVEFORM CAPTURE RATE:500,000wfms/s
DIGITAL CHANNELS:/
STARTING PRICE:
UTD2000CEX+
UTD2000CEX+
BANDWIDTH:50MHz~200 MHz
ANALOG CHANNELS:2
REAL-TIME SAMPLE RATE:1 GSa/s
MAX. MEMORY DEPTH:64 kpts
WAVEFORM CAPTURE RATE:5,000 wfms/s
DIGITAL CHANNELS:/
STARTING PRICE:
UTD2000CL+/CL
UTD2000CL+/CL
BANDWIDTH:25MHz~150MHz
ANALOG CHANNELS:2
REAL-TIME SAMPLE RATE:500MSa/s
MAX. MEMORY DEPTH:64kpts
WAVEFORM CAPTURE RATE:5,000wfms/s
DIGITAL CHANNELS:/
STARTING PRICE:
UTD1000C
UTD1000C
BANDWIDTH:60MHz/100MHz/200MHz
ANALOG CHANNELS:2
REAL-TIME SAMPLE RATE:200MSa/s~1GSa/s
MAX. MEMORY DEPTH:7.5 kpts
WAVEFORM CAPTURE RATE:/
DIGITAL CHANNELS:/
STARTING PRICE:
UTD1000L
UTD1000L
BANDWIDTH:25 MHz~50 MHz
ANALOG CHANNELS:1/2
REAL-TIME SAMPLE RATE:250 MSa/s
MAX. MEMORY DEPTH:12 kpts
WAVEFORM CAPTURE RATE:/
DIGITAL CHANNELS:/
STARTING PRICE:
Obsolete Digital Oscilloscopes (5 items)
