UDP5000 Series DC Switching Power Supplies | Precision Power with 4800W Scalability for Advanced Test Systems

UDP5000 Series DC Switching Power Supplies

Precision Power with 4800W Scalability for Advanced Test Systems

UDP5000 Series delivers precision, flexibility, and high performance in a compact design, making it ideal for R&D, testing, and industrial applications. With 16 models spanning 40 V to 250 V and 400 W to 2000 W, this switching power supply adapts to diverse voltage and current requirements.

Product Image

Key Features

Wide Range Output

Power ratio up to 4.0 enables broader voltage/current combinations at the same power level.

Series/Parallel Operation

Connect 2 units in series (500 V max) or 4 in parallel (480 A max) for outputs up to 4800 W.

Adjustable Slew Rate

Fine-tune voltage and current transitions for sensitive loads.

Battery Simulation

Adjustable internal resistance (0–31.25 Ω) replicates real battery conditions.

CC/CV Priority Modes

Optimize response speed (CV) or minimize overshoot (CC).

Precision & Control

• High Accuracy: Voltage setting resolution of 1 mV, current 1 mA with tight regulation (±0.05% for V, ±0.5% for I).

• Remote Control: Manage via USB, LAN, or web interface.

In Summary

UDP5000 balances versatility with reliability, supporting complex testing scenarios while maintaining user-friendly operation. Ready to optimize your power testing workflow? Contact Us for application-specific configuration advice, Download Datasheet for detailed specifications, or Get a Quote to explore pricing tailored to your needs.
